Rectangular Steel HSS Tube

HSS, standing for hollow structural section, is a hollow structural profile also known as rectangular tube. It is a long steel with a hollow section and no seams around it. Unlike square tube with equal side length, rectangular steel HSS tube have different side lengths.

Classification :

Steel Profile

Keywords :

Steel Profile

WhatsApp : +8617391632933

E-mail :admin@jlccmetal.com

PRODUCT DETAILS

Rectangular Steel HSS Tube Description

HSS usually has two shapes of square and rectangular. Rectangular steel HSS Tube sized usually include 30x20mm, 40x30mm, 40x30mm, 50x30mm, etc. The common wall thickness of HSS tube are generally 0.8mm, 1.0mm, and 1.2mm. The wall thickness of rectangular steel HSS tube varies according to different standards and requirements, and the appropriate wall thickness is selected according to the specific needs. The standard specifications of rectangular steel HSS tube include dimensions, wall thickness, materials and production processes. According to the standards of different countries and regions, the specifications of HSS tube are different. Understanding and complying with the corresponding standard specifications can ensure the quality and performance of rectangular steel HSS tube in use. The material of rectangular steel HSS tube is usually carbon steel, and there is also a small amount of stainless steel. The common materials of carbon steel HSS are Q235B, Q345B, and the common materials of stainless steel HSS are 304, 316. Rectangular steel HSS tubes are widely used in fields including machinery manufacturing, construction industry, metallurgical industry, agricultural vehicles, automobile industry, railways, highway guardrails, container frames, and furniture.

Product Parameters

External Size in Inches	Wall Thickness in Inches	Weight Per Foot
1 1/2 x 3/4	0.063	0.94
2 x 1	0.063	1.27
	0.100	1.82
	0.125	2.21
	0.188	3.05
2 1/2 x 1 1/2	0.125	3.06
3 x 1	0.125	3.06
3 x 1 1/2	0.125	3.48
3 x 1 1/2	0.188	4.96
3 x 2	0.125	3.91
	0.188	5.61
	0.250	7.11
4 x 2	0.125	4.76
	0.188	6.89
	0.250	8.81
	0.313	10.57
4 x 3	0.125	5.61
	0.188	8.17
	0.250	10.51
	0.313	12.69
	0.375	14.71
5 x 2	0.125	5.61
	0.188	8.17
	0.250	10.51
	0.313	12.69
	0.375	14.71
5 x 2 1/2	0.188	8.80
5 x 3	0.125	6.46
	0.188	9.45
	0.250	12.21
	0.313	14.82
	0.375	17.27
6 x 2	0.125	6.46
	0.150	7.66
	0.188	9.42
	0.250	12.21
	0.313	14.82
	0.375	17.26
6 x 3	0.125	7.31
	0.188	10.70
	0.250	13.91
	0.313	16.95
	0.375	19.82
6 x 4	0.188	12.00
	0.250	15.62
	0.313	19.08
	0.375	22.37
	0.500	28.43
7 x 4	0.188	13.25
	0.250	17.31
	0.313	21.20
	0.375	24.92

External Size in Inches	Wall Thickness in Inches	Weight Per Foot
7 x 5	0.188	14.52
	0.250	19.01
	0.313	23.33
	0.375	27.47

Packing And Delivery

The annual steel processing capacity is several million tons, and it is mainly engaged in the research and development, production and sales of stainless steel series, carbon steel series, aluminum series, copper series, galvanized, color coating, coil, seamless pipe, welded pipe, square pipe, torque pipe, round steel, angle steel, channel steel, I-beam, hexagonal Steel, square steel, flat steel, steel wire, welding rod, flange cutting parts and other stainless steel and high nickel alloy steel. for customers to purchase.

FACTORY

There are totally 5 factories,600 employees,50 production lines.Our factory covers an area of 80,000 square meters with advanced production equipment, a laboratory, independent R & D, and an innovation department.We have a whole producing& assembly line consisting of medium-frequency electric furnaces, spectrum analyzers, centrifugal molding, annealing, zinc spray, finishing, and packaging.
